QAD-DUCT Galvanized Steel Duct
Ducts are manufactured as per: DW142 , DW144, SMACNA , ASHRAE
As per consultants specifications using 0.55mm to 1.20mm thickness
Coil/sheet specifications: ASTMA 653 M-LFQ, Z275/ G90/ G (275 Gms / M2)
Uncoiled-chromated regular spangle
QAD-DUCT Black Steel Duct:
Ducting for fire rated and kitchen applications
As per consultants specifications using 1.00mm to 1.5.mm thickness
Hot or cold rolled sheet QAD-DUCT Aluminum Duct:
We are experienced in manufacturing Aluminum duct as per SMACNA and' DW standards.
Manufactured from materials with AA1100 mill finish H14 Temperature.
QAD-DUCT Stainless Steel Duct
We Undertake fabrication in various grades and finishes .
QAD-DUCT Acoustic Liner Insulation
25mm or 50mm black Acoustic insulation 24 kg or 48kg density fixed with self-adhesive hangers comprising of a galvanized steel nail firmly mounted on a galvanized steel base backed by a self-adhesive
Fire Rated Duct
GI duct with fire rated coating
Providing up to 2-4 hours fire rating
Tested and classified by UL, BS476 part 24 and ISO 6944
Spiral Duct
The combination of rigid ducts,fitting with factory mounted sealing strips (a single lip with back-up lip) and a wide range of accessories make the Aerovac® system one of the best and most complete system on the market. Installation saftey has also been given top priority.All the fitting in the Aerovac® system have rounded edges so that fitters are assured of quick and safe handling without any sharp edges.
